Imagine Platinum VX - SFP Module Output Parameters

Platinum™ VX
Installation and Operation Manual Parameters
© 2016 Imagine Communications Corp. Proprietary and Confidential. Version 1.2 | Page 108
OP+SFP+2ORX+NR Dual Optical Receiver Parameters
Table 35: OP+SFP+2ORX+NR Module Input Parameters
Name
Description
Type
Options
Input SFP ID
Reports the type of SFP
RO
OP+SFP+2ORX+NR
Input Port Type
SFP Description
RO
Dual Optical RX
Input SFP Temperature
Displays the internal temperature
for the SFP
RO
Range:-198 to 262 °F
(-128 to 128 °C)
Signal Power
Reports the received power
RO
 No Signal
 -26 to +10 dBm
 Too Low
SFP+HDMI+IN Electrical Receiver Parameters
Table 36: SFP+HDMI+IN Input Parameters
Name
Description
Type
Options
Input SFP ID
Reports the type of SFP
RO
SFP+HDMI+IN
Input Port Type
SFP Description
RO
HDMI RX
Input SFP Temperature
Displays the internal temperature
for the SFP
RO
Range:-198 to 262 °F
(-128 to 128 °C)
Valid TDMS DE
Reports the presence status of
input data
RO
 Yes
 No
Valid TDMS Clock
Reports the presence status of
input clock
RO
 Yes
 No
HDMI Input Module
Reports the detected input signal
mode
RO
 DVI
 HDMI
HDMI Input Video Standard
Reports the detected input signal
standard
RO
 <Detected Standard>
Audio Channel Count
Reports the detected audio
channel numbers.
RO
 Unknown
 2-8
Input Audio Mute
Mutes the output audio
RW
 Yes
 No
SFP Module Output Parameters
In This Section
SFP+2ETX+NR Dual Electrical Transmitter Parameters .......................... 109
SFP+2E+ENC Dual Electrical Transmitter Parameters ............................ 109
OP+SFP+2OTX+13+NR Dual Optical Transmitter Parameters ............... 110
SFP+HDMI+OUT Electrical Transmitter Parameters .............................. 111
Note: Specific parameters displayed correspond to the type of SFP.
