Ethernet Ports
ENET 1
IP Address 1
192.168.100.250
IP Mask 1
255.255.255.0
Gateway Address 1
192.168.100.1
ENET 2
IP Address 2
192.168.101.250
IP Mask 2
255.255.255.0
Gateway Address 2
0.0.0.0
Figure 37: Ethernet Ports on the Rear of an 8 RU Platinum VX Frame
