Platinum™ VX
Installation and Operation Manual Platinum VX Modules
© 2016 Imagine Communications Corp. Proprietary and Confidential. Version 1.2 | Page 48
3. Once you slide the
module in, wait until the
module is positioned in
the frame such that the
top and bottom
extractors come
together easily. Then
slide them into place.
Extracting the Resource/Crosspoint Module from the Frame
1. Locate the Crosspoint Module in the
frame.
