Platinum™ VX
Installation and Operation Manual Platinum VX Modules
© 2016 Imagine Communications Corp. Proprietary and Confidential. Version 1.2 | Page 49
2. Loosen the top and bottom extractors
on the Crosspoint module by gently
pulling the extractors outward.
3. Once the extractors have been
loosened, grasp the upper and lower
extractors and pull outward to slide
the module out of the frame.
