Imagine Platinum VX - Analog Converters

Platinum™ VX
Installation and Operation Manual Platinum VX Specifications and Power
© 2016 Imagine Communications Corp. Proprietary and Confidential. Version 1.2 | Page 75
Item
Specification
Impedance
75 ohms
Return Loss
 3G: >15 dB from 5 MHz to 1485 MHz; >10 dB from 1485
MHz to 2970 MHz
 HD: >15 dB from 5 MHz to 1485 MHz
 SD: >15 dB from 5 MHz to 270 MHz
Signal Level
800 mV ± 10%
D.C. offset
0.0 V ± 0.5 V
Rise and fall time
 3G: <135 ps
 HD: <270 ps
 SD: 0.4 to 1.5 ns
Overshoot
< 10% of amplitude
Jitter
 3G: <2.0 UI (10Hz), <0.3 UI (100KHz)
 HD: <1.0 UI (10Hz), <0.2 UI (100KHz)
 SD: <0.2 UI
Power Consumption
Typical: 340 mW
Analog Converters
SFP+2E+DEC Dual Electrical Receiver Specifications
The SFP+2E+DEC is a dual electrical SFP receiver, designed to decode two video composite (CVBS) signals
over 75 ohm coaxial cables via HD-BNC connectors. The module decodes NTSC/PAL composite inputs
and converts to SD-SDI signals.
Table 24: SFP+2E+DEC Dual Electrical Receiver Specifications
Item
Specification
Connector Type
HD-BNC
Standards
 NTSC, NTSC J, and NTSC 4.43
 PAL-B/G/H/I/D, PAL-M, PAL-N, and PAL-60
Impedance
75 ohms
Return Loss
30 dB (typical) from 0.1 MHz to 6 MHz
Input Level
270 to 830 mV pk-to-pk
Cutoff Frequency (3dB)
Typical: 13 MHz
Passband Flatness
Typical: 0.25 dB (f < 5MHz, VVIN = 0.65 V pk-to-pk,
reference level measured at 1MHz)
Stopband Cutoff
Typical: 53 MHz
Signal-to-Noise Ratio
Typical: 58 dB
