Electrical SFPs
SFP+2ERX+NR Dual Electrical Receiver Specifications
The SFP+2ERX+NR is an electrical dual receiver SFP module, designed to receive two SDI signals at up to
2.97 Gb/s over 75 ohm coaxial cables via HD-BNC connectors. The integrated equalizer features DC
restoration to compensate for the DC content of SMPTE pathological test patterns.
Table 22: SFP+2ERX+NR Dual Electrical Receiver Specifications
Item
Specification
Connector Type
HD-BNC
Standards
 3G: SMPTE 424M (2.97, 2.97/1.001 Gb/s)
 HD: SMPTE 292M (1.485, 1.485/1.001 Gb/s)
 SD: SMPTE 259M-C (270Mb/s, 525/625 component
video)
 ASI: DVB-ASI 270Mb/s
Impedance
75 ohms
Return Loss
 3G: >15 dB from 5 MHz to 1485 MHz; >10 dB from 1485
MHz to 2970 MHz
 HD: >15 dB from 5 MHz to 1485 MHz
 SD: >15 dB from 5 MHz to 270 MHz
Equalization
 3G: 120 m (typical) for Belden 1694A
 HD: >150m for Belden 1694A
 SD: >420m for Belden 1694A; > 320m for Belden 8281B
Power Consumption
Typical: 620 mW
SFP+2ETX+NR Dual Electrical Transmitter Specifications
The SFP+2ETX+NR is a dual electrical SFP transmitter, designed to transmit two SDI signals at up to 2.97
Gb/s over 75 ohm coaxial cables via HD-BNC connectors.
Table 23: SFP+2ETX+NR Dual Electrical Transmitter Specifications
Item
Specification
Connector Type
HD-BNC
Standards
 3G: SMPTE 424M (2.97, 2.97/1.001 Gb/s)
 HD: SMPTE 292M (1.485, 1.485/1.001 Gb/s)
 SD: SMPTE 259M-C (270Mb/s, 525/625 component
video)
 ASI: DVB-ASI 270Mb/s
