Platinum™ VX
Installation and Operation Manual Parameters
© 2016 Imagine Communications Corp. Proprietary and Confidential. Version 1.2 | Page 116
Name
Description
Type
Options
V-Phase
Adjusts the vertical phase of the
frame sync
RW
 0 lines to 524 lines (SD-525)
 0 lines to 624 lines (SD-625)
 0 lines to 749 lines (720p/59.94,
720p/60, 720p/50)
 0 lines to 1124 lines (all 1080i
and 1080p variations)
H-Phase
Adjusts the horizontal phase of
the frame sync
RW
 0.000 us to 63.481 us (SD-525)
 0.000 us to 63.926 us (SD-625)
 0.000 us to 22.231 us
(720p/59.94)
 0.000 us to 26.653 us (720p/50)
 0.000 us to 29.646 us
(1080i/59.94)
 0.000 us to 35.542 us (1080i/50)
 0.000 us to 14.823 us
(1080p/59.94)
 0.000 us to 17.771 us (1080p/50)
LOV Mode
Set the output behavior of the
module during loss of input video
RW
 Pass
 Freeze (Default)
 Black
CQS 1/2 A/B (Advanced)
Table 46: CQS 1/2 A/B (Advanced)
Name
Description
Type
Options
TSG Enable
Enable Test Pattern Generation
RW
 On
 Off
TSG Select
Select test patterns for each SDI
Input (when TSG Enable is active).
RW
 Black
 Color Bars 75%
 Horizontal Sweep Y-only
 Horizontal Sweep
 White
 CrossHatch
