Platinum™ VX
Installation and Operation Manual Parameters
© 2016 Imagine Communications Corp. Proprietary and Confidential. Version 1.2 | Page 119
Category
Name
Description
Type
Options
CQS (1/2 A/B) Ch Gain
(Channels
1A/1B/2A/2B/3A/3B/4A/4B/5A/5
B/6A/6B/7A/7B/8A/8B)
Use this control to adjust the gain
of the designated embedded
audio output channel pairs 1A/1B
to 8A/8B.
 -36.0 dB to 36.0
dB
(0.0 dB default)
Audio Invert
CQS (1/2 A/B) Ch Invert
(Channels
1A/1B/2A/2B/3A/3B/4A/4B/5A/5
B/6A/6B/7A/7B/8A/8B)
This control inverts the selected
audio channel pairs to correct for
phase error.
 Yes
 No
Audio Summing
CQS (1/2 A/B) Ch Summing
(Channels 1A/1B, 2A/2B, 3A/3B,
4A/4B, 5A/5B, 6A/6B, 7A/7B,
8A/8B)
These controls enable or disable
the summing of the designated
output embedded audio pair.
 None
 Right to Left
 Left to Right
 Both
Audio Copy/Swap
CQS (1/2 A/B) Ch Copy/Swap
(Channels 1A/1B, 2A/2B, 3A/3B,
4A/4B, 5A/5B, 6A/6B, 7A/7B,
8A/8B)
Use this control to copy or swap
the designated output embedded
audio pair.
 No Swap
 Swap
 Left to Right
 Right to Left
Audio Mute
CQS (1/2 A/B) Ch Mute
(Channels
1A/1B/2A/2B/3A/3B/4A/4B/5A/5
B/6A/6B/7A/7B/8A/8B)
Individual embedded channels
can be muted using this control.
 Yes
 No
Audio TSG
Table 50: Audio TSG Parameters
Name
Description
Type
Options
Test Tone 400 Hz (dBFS)
Audio test signal generator level
control to adjust the volume of
the audio test tones
RW
6.0 dBFS to 0.0 dBFS
(-18.0 dBFS default)
Test Tone 1 kHz (dBFS)
Audio test signal generator level
control to adjust the volume of
the audio test tones
RW
6.0 dBFS to 0.0 dBFS
(-18.0 dBFS default)
Test Tone 2 kHz (dBFS)
Audio test signal generator level
control to adjust the volume of
the audio test tones
RW
6.0 dBFS to 0.0 dBFS
(-18.0 dBFS default)
Test Tone 4 kHz (dBFS)
Audio test signal generator level
control to adjust the volume of
the audio test tones
RW
6.0 dBFS to 0.0 dBFS
(-18.0 dBFS default)
