Platinum™ VX
Installation and Operation Manual Platinum VX Modules
© 2016 Imagine Communications Corp. Proprietary and Confidential. Version 1.2 | Page 60
650 Watt AC Power Supply for 4/8 RU frames (PV-PS)
A 650 Watt Power Supply (PV-PS) is used in 4 and 8 RU Platinum VX frames. The AC power supply is
rated at 100-240 VAC input, and operates between 90 - 250 VAC.
Table 15: 650 Watt Power Supply Input Specification
Item
Specification
Input Voltage
 Rated: 100 - 240 VAC
 Operating: 90 - 250 VAC
Frequency
 Rated: 50 - 60 Hz
 Operating: 47 - 63 Hz
Input Current
 Rated: 9 A rms maximum
 Operating: 8 A rms maximum at 90 VAC with 650 W output
 Operating: 3 A rms maximum at 250 VAC with 650 W
output
Inrush Current
40A peak maximum @ High Line, hot or cold start, duration
not to exceed 10 ms.
Efficiency
No less than 86% at any net power level greater than 25% of
rated output.
Power Factor
 >0.95 at output power >50% load @ 250 VAC input
 >0.95 at output power >30% load @ 90 VAC input
 >0.97 at 90 to 135 VAC and >0.95 at 180 to 250 VAC, typical
Harmonic Distortion
Complies with the requirements of EN61000-3-2.
The maximum continuous output power is limited to 650 watts. Should the load exceed the maximum
current, or in the event of a short circuit, the power supply will shut down within 110% to 120% of its
maximum current rating. It will resume normal operation upon removal of the offending load / short
within 1 second of removal of the fault condition, in the absence of any other shut-down conditions,
such as thermal.
650 Watt Power Supply Pinouts
Connector Pin Out: Pin
No
Pin Type
Name
Description
A1
Signal
I2C ADDR0
Input
I2C Address Bit 0 (LSB)
A2
Signal
I2C DATA
Bi-directional
I2C Data
A3
Signal
I2C CLK
Input
I2C Clock
A4
Signal
ISHARE
Current sharing, connected
between both PSUs.
B1
Power Blade
GND
Ground
