Platinum™ VX
Installation and Operation Manual Platinum VX Specifications and Power
© 2016 Imagine Communications Corp. Proprietary and Confidential. Version 1.2 | Page 77
Item
Specification
Standards
 525i/625i,
 1080i (50/59.94/60 Hz)
 720p/1080p (23.98/24/25/29.97/30/50/59.94/60 Hz)
 1080p Level B-DL (50/59.94/60 Hz)
TMDS Output Clock Freq
20 to 150 MHz
TMDS Output Clock Duty Cycle
48% to 52%
TMDS Differential Swing
Typical: 1000 mV (800 to 1200 mV)
TMDS Rise/Fall Time
Typical: 175 ps (Min: 75 ps)
Maximum Output Current (5V)
Min: 55 mA
Output Voltage (5V)
Typical: 5.05V (4.8 to 5.3 V)
Power Consumption
Typical: 1030 mW
SFP+HDMI+IN Specifications
The SFP+HDMI+IN is an electrical receiver module designed to convert HDMI input to a SDI format
without scaling artifacts. Up to 4 channels of audio are supported in HDMI mode.
Table 27: SFP+HDMI+IN Specifications
Item
Specification
Connector Type
HDMI 1.4 type-D
Standards
 525i/625i,
 1080i (50/59.94/60 Hz)
 720p/1080p (23.98/24/25/29.97/30/50/59.94/60 Hz)
TMDS Input Clock Freq
20 to 165 MHz
TMDS Clock Duty Cycle
Typical: 50% Minimum: 45%
Intrapair Differential Input
Skew
Min: 0.4 t BIT
Channel-to-Channel
Differential Input Skew
Min: 0.6 t PIXEL
Power Consumption
Typical: 1283 mW
