26. Problems, possible causes, test methods and remedies
Problem
Possible causes
Test method
Remedy
Air motor does not rotate
• Compressed air line interrupted
Connect the test case to the rear
distributor and pressurise the milling air
line. Detect the leaking area.
Open the respective area and replace
the defective air duct.
See instructions:
➔ "...dismantle bubble"
➔ "Removing the axial movement
mechanism"
• Air motor worn out
• Air motor fixed in air motor housing
• Incorrect assembly
• Rotor with burr due to cutter
exchange
(pen extinguisher)
• Lamellae missing
Dismantle the air motor and visually
check the wearing parts.
Assessment of corrosion and
contamination.
Degree at hole for cylindrical pin on
rotor
Clean all parts that are still to be used,
make them corrosion-free and replace
wearing parts.
➔ "Replacing the air motor"
Grind degree on rotor
Air motor without power
• Slats worn out
• Ball bearings run with difficulty
• Air motor heavily soiled
Dismantle the air motor and visually
check the wearing parts.
Assessment of corrosion and
contamination.
Assess the condition of the air motor
housing.
Clean all parts that are still to be used,
make them corrosion-free and replace
wearing parts.
➔ "Replacing the air motor"
• Cylindrical pin in the air motor
housing broken or destroyed
➔ "Replacement of air motor housing or
change of cylindrical pin for air motor"
