Foreword
This Repair Manual provides the technical description of our cutter motors and important information to have
them independently repaired by professionals.
We recommend reading the Repair Manual thoroughly before carrying out the respective repairs.
IMS Robotics GmbH owns all rights to this Repair Manual as well as to its enclosures/pictures. All details and
information are entrusted to the recipient for personal use only.
Information from this Repair Manual must not be disclosed or handed over to third parties, in particular, to
competitors. Therefore, reproduction of this Repair Manual in any form is not permitted.
Liability
IMS Robotics GmbH assumes no liability for direct damage or consequential damage resulting from improper
repair.
In addition, please use only spare parts supplied by IMS Robotics GmbH. IMS Robotics GmbH also assumes no
liability for the use of other products and any resulting damage.
IMS Robotics GmbH reserves the right to make changes to this Repair Manual at any time and without notice in
the event of any technical or typing errors contained in it.
Technical data
Area of application: DN75 - DN150 - with DN250 extension
Power supply: 100 - 240 VAC, 50/60 Hz, max. 1.6 A
Supply air: Free of dirt (particles < 5 micrometres)
Temperature range: +5 °C to max. +40 °C
(41 °F to max. 104 °F)
Residual water separated
Residual oil < 5 mg/m
3
Supply pressure max. 10 bar (145 PSI)
min. Flow rate: 1 m
3
/min (35 CFM)
Water supply: distilled water
