MICRO S automatic Cutter motor
Number:
RH-11.014 A
Scope:
IMS Robotics
Document Management
Date:
08 July 2022
Author:
00145
Checked:
Page:
6 of 113
1. Assembly and testing equipment
Hinge bolt clamp
(005 30 010)
Turned socket wrench. (For mounting the cutter
air hose with the distributor)
(005 45 001)
Spring tensioner for axial spring
(005 30 014)
Threaded rods
(005 30 018)
Mounting ring for lifting air bag
(005 30 022)
Tip
For better handling, a handle can be attached to
one of the threaded rods
