IMS ROBOTICS MICRO S - Page 7

MICRO S automatic Cutter motor
Number:
RH-11.014 A
Scope:
IMS Robotics
Document Management
Date:
08 July 2022
Author:
00145
Checked:
Page:
7 of 113
Nitrogen testing connection (individual strands)
(005 45 006)
Motor housing dummy
(005 45 121)
Dowel pins for removing the cutter
(030 01 757)
Wiring tool
(005 45 009)
Mounting aid press sleeve clamping bubble 8pin.
Bayonet
(005 45 013)
