Nitrogen does not hold or
compressed air enters the nitrogen
system
• Camera cable or screw connections
leaking
Pressurise each bubble with compressed
air and check whether the pressure in
the nitrogen ring is rising.
Nitrogen 0.8 bar / compressed air 2.5
bar
Dismantle the bladder in the affected
area and check the cables and screw
connections for leaks. Seal or replace
leaking parts.
➔ "Connecting the camera cable in the
radial air bag"
➔ "Mounting the front rotary unit"
➔ "Re-route camera cable"
➔ "Replacing the brush unit in the rotary
unit"
