C-COM Satellite Systems Inc. Page 38 of 164
4 – Z (PL Zero)
PL Zero is a converted A/D value from the potentiometer and or a software
generated fixed value from inclinometer that physically determines where the
iNetVu
®
Mobile Software places Polarization Angle 0°. The PL Zero may vary
approximately +15% from the default values for the potentiometer (see Appendix
1) while the inclinometer will provide a more accurate reading with minimal
variances. The PL Zero is used to convert the A/D calculated value during the
polarization calibration process. Polarization calibration is not valid for platforms
(980 and 1200 version 3.0+) and all platforms equipped with the inclinometer tilt
sensor. PL Zero value is set to 90° ± 2 for all tilt sensor equipped units.
7.6.1.5. GP
Displays GPS Status and current GPS Heading.
Fig. 22: “GP” GPS Display
1 – GPS Status
V V GPS Status is Valid, second V is for Velocity Status
F GPS Status has failed
O GPS Coordinates have been overridden
2 – GPS Coordinates
LA Current Latitude Coordinate rounded to one decimal place in degree format.
LG Current Longitude Coordinate rounded to one decimal place in degree format.
7.6.1.6. SM
Displays Search Modes Status, Compass Status, Compass Heading and AZ Window.
Fig. 23: “SM” Search Mode and Compass Display
(See Compass Configuration section under CONF1----SM1 (CP))
GPS: V V0
LA: 45.4N LG: 75.6W
RF :N-N-55-30N
CP:V-000 AZ_W :60
