iNetVu 7000 Series User Manual

C-COM Satellite Systems Inc. Page 40 of 164
7.6.1.7. S1
This menu displays the Target Satellite Number and Longitude, Target Antenna
Coordinates, DVB Transponder (Frequency, Symbol Rate, and Code Rate) and LNB
Power.
Fig. 24: “S1” (Target Satellite) Display
1 - Target satellite number
2 - Target Satellite Longitude and Hemisphere
3 - Target Satellite Antenna Elevation, Azimuth (within reference to true north), and
Polarization coordinates respectively.
4 - Transponder Number
There are usually six (6) transponders for each satellite stored into the controller
memory, 0 – 2 are horizontal receive, and 3-5 are vertical receive, the user may
overwrite the transponder data with his/her own (see configuration section).
5 - DVB Transponder Frequency (MHz)
6 – Transponder Symbol Rate (Ksps)
7 –Transponder Code Rate.
DB-1 = 1/2
DB-2 = 2/3
DB-3 = 3/4
DB-5 = 5/6
DB-7 = 7/8
AUTO (DVB-S2 ACM SELECTION)
8 – Power Supplied to LNB from the 7000 Series Controller for the Target Satellite
3 63W E0 A0 P0
3 0990 30000 DB-7 18
1
5
7
3
6
4
8
2
