C-COM Satellite Systems Inc. Page 66 of 164
8 – Beep
This option allows for enabling and disabling the Beeping sound when navigating the LCD screen
through the front panel keypad.
D – Beep Disabled, the sound will be completely removed.
L – Beep Enabled, a beeping sound will occur every 2 seconds.
M – Beep Enabled, a beeping sound will occur every 1 seconds.
H – Beep Enabled, a beeping sound will occur every 500 milliseconds.
7.6.4.9. C2
Fig. 47: Controller Configuration (Screen 2)
1 – Console Port Configuration
Used for the configuration of the console port of the 7000 Series Controllers. The
Console port could be used for the following:
1) MDM (Modem Communication)
If the COM port is used to establish communication between the
Controller and the VSAT Modem (i.e. iDirect, Viasat, etc.), then MDM
must be selected in this field, along with the Baud Rate the Modem
operates on, prior to configuring the Service, and Communication
Interface.
MDM--4800
MDM--9600
MDM--38400
2) B_R (Beacon Receiver)
The Beacon Receiver is a satellite acquisition lock controller that could be
used alongside the 7000 Series Controller as an option. The Beacon
Receiver will lock on the Beacon Frequency of a satellite based on the
power density of the signal. If the optional Beacon Receiver is used, B_R
must be selected for the console. The default baud rate is 2400.
C :MDM--9600 TO :+0.0
A98A—2.X--3103
To Next Page
