tirb45e1 (2019-02) CDGxxxDxx.cp 15
Index
SI
DataType
NV
Access
PM
Name
1A00 PM RW TxPDO Transmit PDO
Mapping
0x01
BIT
Reading Valid (Module 1)
0x02 BIT Overrange Exceeded
(Module 1)
0x03 BIT Underrange Exceeded
(Module 1)
0x04
BIT
Padding Bits 1 (5 bit)
0x05
REAL
Sensor Value (Module 1)
1A01 PM RW TxPDO Transmit PDO
Mapping, User Mapping
1A02 PM RW TxPDO Transmit PDO
Mapping
0x01
BIT
Reading Valid (Module 2)
0x02 BIT Overrange Exceeded
(Module 2)
0x03 BIT Underrange Exceeded
(Module 2)
0x04
BIT
Padding Bits 1 (5 bit)
0x05
REAL
Sensor Value (Module 2)
1A03 PM RW TxPDO Transmit PDO
Mapping, User Mapping
1BFE PM RW Transmit PDO Mapping
0x01
BYTE
Active Exception Status
0x02 UDINT Trip Point Output All
Instance
1BFF PM RW Transmit PDO Mapping
User Mapping
1C00 0x01
0x02
0x03
0x04
BYTE RW Sync Manager Type
1C12 /
1C13
0x01
0x02
0x03
0x04
UINT RW Sync Manager PDO
Assignment
1C32 /
1C33
0x01
-
0x20
RW Sync Manager Parameter
The manufacturer-specific profile objects contain the manufacturer's model number
and device configuration data, status and diagnostic data. The objects are
described in the following tables.
Index
SI
DataType
NV
Access
PM
Name
2000
0x01
BYTE
RO
Status
Alarm and Warning State of Module 1
Bit 0
Bit 1
Bit 2
Bit 3
Bit 4…7
High Alarm Exception (0 = cleared, 1 = set)
Low Alarm Exception (0 = cleared, 1 = set)
High Warning Exception (0 = cleared, 1 = set)
Low Warning Exception (0 = cleared, 1 = set)
0
TxPDO's
4.3 Manufacturer-specific
Profile Objects
(0x2000...0x5FFF)
4.3.1 Manufacturer Status
Subindex 0x01
