tirb45e1 (2019-02) CDGxxxDxx.cp 21
Low Trip Hysteresis: Hysteresis value for Low Trip Point.
Object index of active source of (I 0x900E SI 0x01) Input Value.
Source Index
Bit 16…31
Bit 08…15
Bit 00…07
Index
Subindex
Reserved
Calculating the High Trip Point and Low Trip Point chapter 4.5.2.
Index
SI
DataType
NV
Access
PM
Name
800F
0x01
BOOL
x
RW
High Trip Enable
0x02
BOOL
x
RW
Low Trip Enable
0x11
REAL
x
RW
High Trip Point Limit
0x13 REAL x RW Percentage High Trip
Source
0x14
REAL
x
RW
Low Trip Point Limit
0x17
REAL
x
RW
High Trip Hysteresis
0x18
REAL
x
RW
Low Trip Hysteresis
0x1A
UDINT
x
RW
Source Index
High Trip Point
0
1
Disable
Enable
Low Trip Point
0
1
Disable
Enable
High Trip Point limit: High limit to trigger trip point condition if Input Value (I 0x900F,
SI 0x01) is above this limit.
Percentage of High Trip Source: Percentage of Piezo Sensor Value (I 0x60010,
SI 0x11) in [%].
Low Trip Point Limit: Low limit to trigger trip point condition if Input Value (I 0x900F,
SI 0x01) is below this limit.
High Trip Hysteresis: Hysteresis value for High Trip Point.
Low Trip Hysteresis: Hysteresis value for Low Trip Point.
Object index of active source of (I 0x900F SI 0x01) Input Value.
Source Index
Bit 16…31
Bit 08…15
Bit 00…07
Index
Subindex
Reserved
Subindex 0x18
Subindex 0x1A
4.5.4 Configuration Trip
Point 2
Subindex 0x01
Subindex 0x02
Subindex 0x11
Subindex 0x13
Subindex 0x14
Subindex 0x17
Subindex 0x18
Subindex 0x1A
