Inficon CDG045D2 - Information Device

tirb45e1 (2019-02) CDGxxxDxx.cp 31
Index
SI
DataType
NV
Access
PM
Name
F940
0x01
UDINT
RO
Measurement Principle
0x02
BYTE
RO
Number of Sensors
0x04 V_STRING x RO SW Version VPG PCB
F9F0 V_STRING RO Manufacturer Serial
Number
F9F1 0x01 UDINT RO CDP Functional
Generation Number
F9F2 0x01 UDINT RO SDP Functional
Generation Number
(Module 1)
0x02 UDINT RO SDP Functional
Generation Number
(Module 2)
F9F3
V_STRING
RO
Vendor Name
F9F4 0x01 V_STRING RO Semiconductor SDP
Device Name (Module 1)
0x02 V_STRING RO Semiconductor SDP
Device Name (Module 2)
F9F5 0x01 USINT RW Rx
Tx
Output Identifier
(Module 1)
0x02 USINT RW Rx
Tx
Output Identifier
(Module 2)
F9F6
UDINT
RO
Time since power on
F9F7
UDINT
x
RO
Total time powered
F9F8 UDINT RO Firmware Update
Functional Generation
Number
Measurement principle assigned to the object instance.
The most significant nibble of the parameter represents the sensor type of the first
Module, the second most significant nibble of the parameter represents the sensor
type of the second Module, and so forth.
Measurement Principle (Index F940)
1
2
3
4
5
Capacitance Manometer
Piezo
Heat Transfer
Cold Cathode
Hot Cathode
Number of Sensors (Index F940): The number of sensors implemented on the
device.
If the device consists out of several software portions this parameter should be
used.
Using standard a.b.c.d format to describe a version:
SW Version VPG PCB (Index F940)
a
b
c
d
Mayor revision
Minor revision
Development revision
Vendor specific
i.e. 1.0.1.2
4.7.21 Information Device
Subindex 0x01 (F940)
Subindex 0x02 (F940)
Subindex 0x04 (F940)
