Inficon CDG045D2 User Manual

16 tirb45e1 (2019-02) CDGxxxDxx.cp
Index
SI
DataType
NV
Access
PM
Name
4000
0x01
BYTE
RW
Safe State
0x02
REAL
RW
Safe Value
0x03 BOOL RW Alarm Enable
0x04
BOOL
RW
Warning Enable
0x05
REAL
RW
Alarm Trip Point High
0x06
REAL
RW
Alarm Trip Point Low
0x07
REAL
RW
Alarm Hysteresis
0x08
REAL
RW
Warning Trip Point High
0x09
REAL
RW
Warning Trip Point Low
0x0A
REAL
RW
Warning Hysteresis
0x0B
BYTE
RW
Filter
Specifies the behavior for the value for States other than Valid.
Safe State
0
1
2
3
Zero
Full Scale
Hold last value
Use safe value
Safe Value: The value to be used for Safe State = Safe Value.
Alarm Enable: Enables the setting of the Alarm Status Bits.
Warning Enable: Enables the setting of the Warning Status Bits.
Alarm Trip Point High: Determines the value above which an Alarm Condition will
occur.
Alarm Trip Point Low: Determines the value below which an Alarm Condition will
occur.
Alarm Hysteresis: Determines the amount by which the value must recover to clear
an Alarm Condition.
Warning Trip Point High: Determines the value above which a Waning Condition
will occur.
Warning Trip Point Low: Determines the value below which a Waning Condition will
occur.
Warning Hysteresis: Determines the amount by which the value must recover to
clear a Warning Condition.
Filter
0
1
2
Dynamic (factory default)
Fast
Slow
4.3.2 Manufacturer
Configuration (Module 1)
Subindex 0x01
Subindex 0x02
Subindex 0x03
Subindex 0x04
Subindex 0x05
Subindex 0x06
Subindex 0x07
Subindex 0x08
Subindex 0x09
Subindex 0x0A
Subindex 0x0B
