30 tirb45e1 (2019-02) CDGxxxDxx.cp
Status of Trip Point instances.
Trip Point Output All Instance
Bit 0
Bit 1
Bit 2
Bit 3
Bit 431
Status High Trip (I 0x600E, SI 0x01)
Status Low Trip (I 0x600E S,I 0x02)
Status High Trip (I 0x600F, SI 0x01)
Status Low Trip (I 0x600F, SI 0x02)
not used = 0
Index
SI
DataType
NV
Access
PM
Name
F6F0 0x01 UDINT RO tx Input Latch Local
Timestamp. Mandatory if
device has inputs
(TxPDOs)
0x02 UDINT RO tx Input Latch Local
Timestamp. Mandatory if
device has inputs
(TxPDOs)
Local controller time corresponding to the input latch time in microseconds. It starts
at zero on device power-up. Mandatory if device has inputs. If device has no
inputs defined, this corresponds the time immediately prior to writing to input SM.
Local controller time corresponding to the input latch time in microseconds. It starts
at zero on device power-up. Mandatory if device has inputs. If device has no
inputs defined, this corresponds the time immediately prior to writing to input SM.
Index
SI
DataType
NV
Access
PM
Name
F840
0x01
UDINT
x
RW
Data Units
0x03
Enum
x
RW
Data Units Enum
Unit of the Value of the Analog Input Sensor Instance and all related parameters.
Trip Point Output All Instance
0x00220000
0xFD4E0000
0x00A10000
Pascal
mbar
Torr
If this value is changed, also Subindex 3 will change the value acorgingly.
Data Unit for Input Sensor as Enum to have a list of possible values.
Data Units
0x01(Pa)
0x04(mBar)
0x05(Torr)
Pascal
mbar
Torr
If this value is changed, also Subindex 1 will change the value accordingly.
Subindex 0x01
4.7.19 Input Latch Local
Timestamp
Subindex 0x01
Subindex 0x02
4.7.20 Configure Device
Subindex 0x01
Subindex 0x03
