Inficon CDG045D2 User Manual

tirb45e1 (2019-02) CDGxxxDxx.cp 7
1 Technical Data
For further technical data refer to the appropriate documents:
CDG025D2 →  [4]
CDG045D →  [1]
CDG045D2 →  [5]
CDG045Dhs →  [6]
CDG100D →  [2]
CDG100D2 →  [5]
CDG100Dhs
→ 
[7]
CDG160D →  [3]
CDG160Dhs →  [8]
CDG200D →  [3]
CDG200Dhs →  [8]
Communication protocol
protocol specialized for EtherCAT
Communication standards ETG.5003.1 S (R) V1.1.0: Part 1 Common
Device Profile (CDP) (→  [17]
)
ETG.5003.2080 S (R) V1.3.0: Part 2080:
Specific Device Profile (SDP) Vacuum
Pressure Gauge (
→ 
[18])
Data rate
100 Mbps
Node address Explicit Device Identification
Physical layer
100BASE-Tx (IEEE 802.3)
EtherCAT connector 2 × RJ45, 8-pin (socket)
<IN>: EtherCAT input
<OUT>: EtherCAT output
Cable shielded, special Ethernet Patch Cable
(CAT5e quality or higher)
Cable length
≤100 m
Process data Fixed PDO mapping and configurable PDO
mapping
Mailbox (CoE)
SDO requests, responses and information
EtherCAT interface
