tirb45e1 (2019-02) CDGxxxDxx.cp 23
Lowest Informational Measurement Value: Lowest value that the gauge can
measure without a specified accuracy.
Index
SI
DataType
NV
Access
PM
Name
9001
0x01
UINT
RO
Sensor Warning
0x02
UINT
RO
Sensor Error
Sensor Warnings
Bit 0
Bit 1…8
Bit 9
Bit 10…13
Bit 14
Bit 15
Not at temperature
0
Electronics Warning
0
Low Warning Exception
High Warning Exception
Sensor Errors
Bit 0…8
Bit 9
Bit 10…13
Bit 14
Bit 15
0
Electronics Failure
0
Low Error Exception
High Error Exception
Index
SI
DataType
NV
Access
PM
Name
9010
0x01
REAL
x
RO
Accumulated Zero Offset
0x02 REAL x RO Highest Informational
Measurement Value
0x03 REAL x RO Highest Precision
Measurement Value
0x04 REAL x RO Lowest Precision
Measurement Value
0x05 REAL x RO Lowest Informational
Measurement Value
Accumulated Zero Offset: An amount added prior to Gain to derive Value. Result of
Zero Adjust Command (accumulated value).
Highest Informational Measurement Value: Highest value that the gauge can
measure without a specified accuracy.
Highest Precision Measurement Value: Highest valid value at which the gauge is
specified with an accuracy value. Above that value, the parameter Reading Valid is
set to invalid.
Lowest Precision Measurement Value: Lowest valid value at which the gauge is
specified with an accuracy value. Below that value, the parameter Reading Valid is
set to invalid.
Lowest Informational Measurement Value: Lowest value that the gauge can
measure without a specified accuracy.
Subindex 0x05
4.6.2 Information Capacitance
Diaphragm
Subindex 0x01
Subindex 0x02
4.6.3 Information Common
Piezo
Subindex 0x01
Subindex 0x02
Subindex 0x03
Subindex 0x04
Subindex 0x05
