Inficon CDG045D2 User Manual

tirb45e1 (2019-02) CDGxxxDxx.cp 5
Contents
General Information 2
Intended Use 2
EtherCAT–Interface 2
Product Identification 2
Validity 3
Trademarks 4
Patents 4
1 Technical Data 7
2 Interface Connection 8
3 Operation 10
3.1 Introduction 10
3.2 Front View 10
3.3 Indicators and Switches 11
3.3.1 <RUN> LED 11
3.3.2 <ERR> LED 11
3.3.3 <LA> LED (<IN> Port) 11
3.3.4 <LA> LED (<OUT> Port) 11
3.3.5 Device Address Switch 12
4 Object Structure CDG025D2, CDG045D, CDG045D2, CDG100D,
CDG100D2, CDG160D, CDG200D 13
4.1 Object Dictionary structure 13
4.2 Communication Profile Objects (0x1000…0x1FFF) 14
4.2.1 Process Data Objects (PDO's) 14
4.3 Manufacturer-specific Profile Objects (0x2000...0x5FFF) 15
4.3.1 Manufacturer Status 15
4.3.2 Manufacturer Configuration (Module 1) 16
4.3.3 Manufacturer Configuration (Module 2) 17
4.4 Input Area (0x6000…0x6FFF) 17
4.4.1 Input Common 17
4.4.2 Input Capacitance Diaphragm 17
4.4.3 Input Common 18
4.4.4 Input Piezo 18
4.4.5 Input Trip Point 1 18
4.4.6 Input Trip Point 2 19
4.5 Configuration Area (0x8000…0x8FFF) 19
4.5.1 Configuration Capacitance Diaphragm 19
4.5.2 Configuration Trip Point 19
4.5.3 Configuration Trip Point 1 20
4.5.4 Configuration Trip Point 2 21
4.6 Information Area (0x9000…0x9FFF) 22
4.6.1 Information Common Capacitance Diaphragm 22
4.6.2 Information Capacitance Diaphragm 23
4.6.3 Information Common Piezo 23
4.6.4 Information Piezo 24
4.6.5 Information Trip Point 1 / 2 24
4.7 Device Area (0xF000...0xAFFF) 24
4.7.1 Semiconductor Device Profile 24
4.7.2 Module Profile List 24
4.7.3 Exceptions 25
4.7.4 Active Exception Status 25
4.7.5 Active Device Warning Details 25
4.7.6 Active Device Error Details 26
4.7.7 Active Global Device Warning Details 26
4.7.8 Active Global Device Error Details 27
4.7.9 Latched Device Warning Details 27
4.7.10 Latched Device Error Details 27
4.7.11 Latched Global Device Warning Details 28
4.7.12 Latched Global Device Error Details 28
4.7.13 Device Warning Mask 28
4.7.14 Device Error Mask 29
4.7.15 Global Device Warning Mask 29
4.7.16 Global Device Error Mask 29
4.7.17 Manufacturer Information Device 29
4.7.18 Trip Point Output All 29
4.7.19 Input Latch Local Timestamp 30
