2 tirb45e1 (2019-02) CDGxxxDxx.cp
Data transmission errors
Any attempt to simultaneously operate the gauge via the RS232C
Serial Interface and EtherCAT interface or the diagnostic port may
result in incorrect data and data transmission errors.
Therefore, it is inadmissible to simultaneously operate the gauge via
the RS232C Serial Interface and EtherCAT interface, or the diagnostic
port.
This Communication Protocol contains instructions for operating EtherCAT inter-
faces (slaves) together with a master.
For safety information, specifications and operation instructions of the
vacuum gauges refer to the appropriate documents:
CDG025D2 →  [4]
CDG045D →  [1]
CDG045D2 →  [5]
CDG045Dhs →  [6]
CDG100D →  [2]
CDG100D2 →  [5]
CDG100Dhs →  [7]
CDG160D →  [3]
CDG160Dhs →  [8]
CDG200D →  [3]
CDG200Dhs →  [8]
The following description of the EtherCAT interface is compliant to the EtherCAT
specification of the EtherCAT Technology Group (ETG) and to the  "EtherCAT
Semiconductor Device Profile".
This manual describes the functionality of a EtherCAT slave and supports
• ETG.5003.1 S (R) V1.1.0: Part 1 Common Device Profile (CDP) (→  [17])
and
• ETG.5003.2080 S (R) V1.3.0: Part 2080: Specific Device Profile (SDP) Vacuum
Pressure Gauge (→  [18]).
For operating the gauge via EtherCAT, prior installation of the device specific ESI
file is required on the bus master side. This file can be downloaded from our web-
site.
In all communications with INFICON, please specify the information on the product
nameplate. For convenient reference copy that information into the space provided
below.
Caution
General Information
Intended Use
EtherCAT–Interface
Product Identification
