Inficon CDG045D2 User Manual

tirb45e1 (2019-02) CDGxxxDxx.cp 25
Index
SI
DataType
NV
Access
PM
Name
F380
USINT
RO
tx
ActiveException Status
Active Exception Status
Bit 0
Device Warning
Bit 1
Manufacturer Warning
Bit 2
Device Error
Bit 3
Manufacturer Error
Bit 4…7
0
The "active device warning details" parameter describes the warning state of the
complete device.
Index
SI
DataType
NV
Access
PM
Name
F381 0x01 UDINT RO tx Active Device Warning
Details
0x02 UDINT RO tx Active Device Warning
Details
F382 0x01 UDINT RO tx Active Manufacturer
Warning Details
0x02 UDINT RO tx Active Manufacturer
Warning Details
Active Device Warning Details (Index F381, Module 1)
Bit 0
Not at temperature
Bit 1…8
0
Bit 9
Electronics warning
Bit 10…13
0
Bit 14
Low Warning Exception
Bit 15
High Warning Exception
Bit 16…31
0
Active Device Warning Details (Index F381, Module 2)
Bit 0…31
0
Active Manufacturer Warning Details (Index F382, Module 1)
Bit 0…31
0
Active Manufacturer Warning Details (Index F382, Module 2)
Bit 0…31
0
4.7.3 Exceptions
4.7.4 Active Exception Status
Active Exception Status
4.7.5 Active Device Warning
Details
Subindex 0x01 (F381)
Subindex 0x02 (F381)
Subindex 0x01 (F382)
Subindex 0x02 (F382)
