Inficon CDG045D2 User Manual

50 tirb45e1 (2019-02) CDGxxxDxx.cp
The "active device warning details" parameter describes the warning state of the
complete device.
Index
SI
DataType
NV
Access
PM
Name
F381 0x01 UDINT RO tx Active Device Warning
Details
0x02 UDINT RO tx Active Device Warning
Details
F382 0x01 UDINT RO tx Active Manufacturer
Warning Details
0x02 UDINT RO tx Active Manufacturer
Warning Details
Active Device Warning Details (Index F381, Module 1)
Bit 0
Not at temperature
Bit 1…13
0
Bit 14
Low Warning Exception
Bit 15
High Warning Exception
Bit 16…31
0
Active Device Warning Details (Index F381, Module 2)
Bit 0…31
0
Active Manufacturer Warning Details (Index F382, Module 1)
Bit 0…31
0
Active Manufacturer Warning Details (Index F382, Module 2)
Bit 0…31
0
The "active device error details" parameter describes the error state of the
complete device.
Index
SI
DataType
NV
Access
PM
Name
F383
0x01
UDINT
RO
tx
Active Device Error Details
0x02
UDINT
RO
tx
Active Device Error Details
F384 0x01 UDINT RO tx Active Manufacturer Error
Details
0x02 UDINT RO tx Active Manufacturer Error
Details
Active Device Error Details (Index F383, Module 1)
Bit 0
Diaphragm Failure
Bit 1
Electronics Failure
Bit 2
Electronics Over Temperature
Bit 3…13
0
Bit 14
Low Error Exception
Bit 15
High Error Exception
Bit 16…31
0 (reserved)
Active Device Error Details (Index F383, Module 2)
Bit 0
Sensor Failure Piezo Sensor
Bit 1…31
0
5.7.5 Active Device Warning
Details
Subindex 0x01 (F381)
Subindex 0x02 (F381)
Subindex 0x01 (F382)
Subindex 0x02 (F382)
5.7.6 Active Device Error
Details
Subindex 0x01 (F383)
Subindex 0x02 (F383)
