64 tirb45e1 (2019-02) CDGxxxDxx.cp
Index Object
Code
Sub
Index
Data
Type
Ac-
cess
B/S PM Name Description
0xF641
RECORD
RO
Trip Point Output All
Trip Point Output All
0xF641 0x01 UDINT RO TX
Trip Point Output All
Instance
Status of Trip Point Instances
Bit 0: Status High Trip
(I 0x6nnE, SI 0x01)
Bit 1: Status Low Trip
(I 0x6nnE, SI 0x02)
Bit 2: Status High Trip
(I 0x6nnF, SI 0x01)
Bit 3: Status Low Trip
(I 0x6nnF, SI 0x02)
Bit 4…31: 0
Trip Point 1 / 2
CDGxxxD, CDGxxxD2
CDGxxxDhs
29
54
[1] www.inficon.com
Operating Manual
Sky CDG045D
tina51d1 (German)
tina51e1 (English)
INFICON AG, LI9496 Balzers, Liechtenstein
[2] www.inficon.com
Operating Manual
Sky CDG100D
tina52d1 (German)
tina52e1 (English)
INFICON AG, LI9496 Balzers, Liechtenstein
[3] www.inficon.com
Operating Manual
Sky CDG160D, CDG200D
tina53d1 (German)
tina53e1 (English)
INFICON AG, LI9496 Balzers, Liechtenstein
[4] www.inficon.com
Operating Manual
Edge CDG025D2
tinb28d1 (German)
tinb28e1 (English)
INFICON AG, LI9496 Balzers, Liechtenstein
[5] www.inficon.com
Operating Manual
Edge CDG045D2, CDG100D2
tina86d1 (German)
tina86e1 (English)
INFICON AG, LI9496 Balzers, Liechtenstein
[6] www.inficon.com
Operating Manual
Stripe CDG045Dhs
tina84d1 (German)
tina84e1 (English)
INFICON AG, LI9496 Balzers, Liechtenstein
Trip Point All Slots Combined
