Inficon CDG045D2 - Device Error Mask; Global Device Warning Mask; Global Device Error Mask; Manufacturer Information Device

tirb45e1 (2019-02) CDGxxxDxx.cp 29
Index
SI
DataType
NV
Access
PM
Name
F3A3
0x01
UDINT
x
RW
Device Error Mask
0x02
UDINT
x
RW
Device Error Mask
F3A4 0x01 UDINT x RW Manufacturer Error Mask
0x02
UDINT
x
RW
Manufacturer Error Mask
Device Error Mask: Mask bits for 0xF383:01 and 0xF393:01.
Device Error Mask: Mask bits for 0xF383:02 and 0xF393:02.
Manufacturer Error Mask: Mask bits for 0xF384:01 and 0xF394:01.
Manufacturer Error Mask: Mask bits for 0xF384:02 and 0xF394:02.
Index
SI
DataType
NV
Access
PM
Name
F3A5 0x01 UDINT x RW Global Device Warning
Mask
F3A6 0x01 UDINT x RW Global Manufacturer
Warning Mask
Global Device Warning Mask: Mask bits for 0xF385:01 and 0xF395:01.
Global Manufacturer Warning Mask: Mask bits for 0xF386:01 and 0xF396:01.
Index
SI
DataType
NV
Access
PM
Name
F3A7
0x01
UDINT
x
RW
Global Device Error Mask
F3A8 0x01 UDINT x RW Global Manufacturer Error
Mask
Global Device Error Mask: Mask bits for 0xF387:01 and 0xF397:01.
Global Manufacturer Error Mask: Mask bits for 0xF388:01 and 0xF398:01.
Index
SI
DataType
NV
Access
PM
Name
F500 V_STRING RO Manufacturer's Model
Number
F501
V_STRING
RO
Device Configuration
Index
SI
DataType
NV
Access
PM
Name
F641 0x01 UDINT RO tx Trip Point Output All
Instance
4.7.14 Device Error Mask
Subindex 0x01 (F3A3)
Subindex 0x02 (F3A3)
Subindex 0x01 (F3A4)
Subindex 0x02 (F3A4)
4.7.15 Global Device Warning
Mask
Subindex 0x01 (F3A5)
Subindex 0x01 (F3A6)
4.7.16 Global Device Error
Mask
Subindex 0x01 (F3A7)
Subindex 0x01 (F3A8)
4.7.17 Manufacturer
Information Device
4.7.18 Trip Point Output All
