Execution of this command will start a Zero Adjust operation.
The zeroing function is locked in order for operating errors to be
prevented, therefore see the operation instructions of the vacuum
gauges, refer to the appropriate documents (→  [1] … [8]).
Index
SI
DataType
NV
Access
PM
Name
FB40
0x01
V_STRING(6)
RW
Command
0x02
BYTE
RO
Status
0x03
V_STRING(3)
RO
Response
Command
Byte 0
0: Zero adjust with no offset
Byte 1
Index of the Sub Sensor Instance (1)
Byte 2…5
Offset value (Data format: REAL, always 0)
Status (supported values)
0
1
2
3
255
Last command completed, no errors, no reply available
Last command completed, no errors, reply available
Last command completed, errors present, no reply
available
Last command completed, errors present, reply available
Command is executing
Response
Byte 0
See Subindex 0x02
Byte 1
Unused
Byte 2 0: Zeroing successful
1: Zeroing failed; out-of-range
2: Zeroing failed; cumulative out-of-range
3: Zeroing failed: measurement invalid
254: No previous Zero Adjust command issued
Execution of this command will start a Full Scale Adjust operation.
Index
SI
DataType
NV
Access
PM
Name
FB41
0x01
V_STRING(6)
RW
Command
0x02
BYTE
RO
Status
0x03
V_STRING(3)
RO
Response
Command
Byte 0
0: Full Scale Adjust
Byte 1
2: Index of the Sub Sensor Instance (always 2)
Byte 2…5
0: Full Scale value (Data format: REAL, always 0)
Status (supported values)
0
1
2
3
255
Last command completed, no errors, no reply available
Last command completed, no errors, reply available
Last command completed, errors present, no reply
available
Last command completed, errors present, reply available
Command is executing
5.8.2 Command Zero Adjust
Subindex 0x01
Subindex 0x02
Subindex 0x03
5.8.3 Full Scale Adjust
Subindex 0x01
Subindex 0x02
