tirb45e1 (2019-02) CDGxxxDxx.cp 45
Percentage of High Trip Source: Percentage of Piezo Sensor Value (I 0x6010,
SI 0x11) in [%].
Low Trip Point Limit: Low limit to trigger trip point condition if Input Value (I 0x900E,
SI 0x01) is below this limit.
Object index of Low Trip Point Value source. Index of Low Trip Point Limit
(I 0x800E, SI 0x14)
Bit 16…31: Index
Bit 08…15: Subindex
Bit 00…07: reserved
It is only possible to reference to "Low Trip Point Limit" (I 0x800E, SI 0x14) or
"Input Piezo Module 2" "Sensor Value" (I 0x6010, SI 0x11).
Percentage of Value referenced by Low Trip Source Index in [%]. If Low Trip
Source Index is I 0x800E, SI 0x14 this parameter is not used.
High Trip Hysteresis: Hysteresis value for High Trip Point.
Low Trip Hysteresis: Hysteresis value for Low Trip Point.
Object index of active source of (I 0x900E SI 0x01) Input Value.
Source Index
Bit 16…31
Bit 08…15
Bit 00…07
Index
Subindex
Reserved
Calculating the High Trip Point and Low Trip Point → chapter 5.5.2.
Index SI DataType NV Access PM Name
800F
0x01
BOOL
x
RW
High Trip Enable
0x02
BOOL
x
RW
Low Trip Enable
0x11
REAL
x
RW
High Trip Point Limit
0x12
UDINT
x
RW
High Trip Source Index
0x13 REAL x RW Percentage High Trip
Source
0x14
REAL
x
RW
Low Trip Point Limit
0x15
UDINT
x
RW
Low Trip Source Index
0x16 REAL x RW Percentage Low Trip
Source
0x17
REAL
x
RW
High Trip Hysteresis
0x18
REAL
x
RW
Low Trip Hysteresis
0x1A
UDINT
x
RW
Source Index
High Trip Point
0
1
Disable
Enable
Subindex 0x13
Subindex 0x14
Subindex 0x15
Subindex 0x16
Subindex 0x17
Subindex 0x18
Subindex 0x1A
5.5.4 Configuration Trip
Point 2
Subindex 0x01
