Specifies the behavior for the Value for states other than Valid.
Safe State
0
1
2
3
Zero
Full Scale
Hold last value
Use safe value
Safe Value: The value to be used for Safe State = Safe Value.
Index SI DataType NV Access PM Name
6000
0x0E
BOOL
RO
tx
TxPdoState
0x11
REAL
RO
tx
Sensor Value
Is set if the device is not in Safe State (value (I 0x6nn0, SI 0x11) = valid)
TxPdoState
0
1
Invalid
Valid
The corrected, converted, calibrated final analog input value of the sensor.
Index
SI
DataType
NV
Access
PM
Name
6001
0x01
BOOL
RO
tx
Reading Valid
0x02
BOOL
RO
tx
Overrange Exceeded
0x03
BOOL
RO
tx
Underrange Exceeded
Indicates whether the Value parameter contains a valid value within the specified
accuracy or not.
Reading Valid
0
Invalid
1
Valid
Indicates whether the Value parameter contains a value in over range.
Reading Valid
0
No Overrange Exceeded
1
Overrange Exceeded
Indicates whether the Value parameter contains a value in under range.
Reading Valid
0
No Underrange Exceeded
1
Underrange Exceeded
Subindex 0x01
Subindex 0x02
5.4 Input Area
(0x6000…0x6FFF)
5.4.1 Input Common
Subindex 0x0E
Subindex 0x11
5.4.2 Input Capacitance
Diaphragm
Subindex 0x01
Subindex 0x02
Subindex 0x03
