Inficon CDG045D2 User Manual

52 tirb45e1 (2019-02) CDGxxxDxx.cp
Active Global Manufacturer Error Details (Index F388)
Bit 0 Internal Communication Exception (between
EtherCAT-Protocol and Device-Application)
Bit 1
0
Bit 2
Over temperature board
Bit 3
Zero adjust value lager than error limit
Bit 4 Communication with AD-Converter for heat
temperature is not possible
Bit 5 No meaningful temperature value from PT1000
sensor
Bit 6…31
0
Index
SI
DataType
NV
Access
PM
Name
F390
USINT
RO
tx
Latched Exceptions Status
F391 0x01 UDINT RO tx Latched Device Warning
Details
0x02 UDINT RO tx Latched Device Warning
Details
F392 0x01 UDINT RO tx Latched Manufacturer
Warning Details
0x02 UDINT RO tx Latched Manufacturer
Warning Details
Latched version of 0xF380.
Latched Device Warning Details: Latched version of 0xF381:01.
Latched Device Warning Detail: Latched version of 0xF381:02.
Latched Manufacturer Warning Details: Latched version of 0xF382:01.
Latched Manufacturer Warning Details: Latched version of 0xF382:01.
Index
SI
DataType
NV
Access
PM
Name
F393 0x01 UDINT RO tx Latched Device Error
Details
0x02 UDINT RO tx Latched Device Error
Details
F394 0x01 UDINT RO tx Latched Manufacturer
Error Details
0x02 UDINT RO tx Latched Manufacturer
Error Details
Latched Device Error Details: Latched version of 0xF383:01.
Latched Device Error Details: Latched version of 0xF383:02.
Latched Manufacturer Error Details: Latched version of 0xF384:01.
Latched Manufacturer Error Details: Latched version of 0xF384:02.
Subindex 0x01 (F388)
5.7.9 Latched Device Warning
Details
Latched Exceptions Status
Subindex 0x01 (F391)
Subindex 0x02 (F391)
Subindex 0x01 (F392)
Subindex 0x02 (F392)
5.7.10 Latched Device Error
Details
Subindex 0x01 (F393)
Subindex 0x02 (F393)
Subindex 0x01 (F394)
Subindex 0x02 (F394)
