Inficon CDG045D2 - Device Area (0 Xf000; Semiconductor Device Profile; Module Profile List; Exceptions

tirb45e1 (2019-02) CDGxxxDxx.cp 49
Index
SI
DataType
NV
Access
PM
Name
900E
0x01
REAL
RO
Input Value Trip Point 1
900F
0x01
REAL
RO
Input Value Trip Point 2
Input Value Trip Point 1: Trip Point Input value as referenced by Source Index (I
0x800E, SI 0x0E).
Input Value Trip Point 2: 0 Trip Point Input value as referenced by Source Index (I
0x800F, SI 0x0E).
Index
SI
DataType
NV
Access
PM
Name
F000
0x01
UINT
RO
Index Distance
0x02 UINT RO Maximum Number of
Modules
Index Distance: Index offset between PDO entries of two consecutive modules (for
ETG.5003 = 0x10), e.g. 0x6000, 0x6010.
Number of Modules: CDGxxxD has always 2.
Index
SI
DataType
NV
Access
PM
Name
F010
0x01
UDINT
RO
Profile Number (Module 1)
0x02
UDINT
RO
Profile Number (Module 2)
Each sub-index lists the profile-number of the corresponding module.
Each sub-index lists the profile-number of the corresponding module.
Index
SI
DataType
NV
Access
PM
Name
F380
USINT
RO
tx
ActiveException Status
Active Exception Status
Bit 0
Device Warning
Bit 1
Manufacturer Warning
Bit 2
Device Error
Bit 3
Manufacturer Error
Bit 4…7
0
5.6.5 Information Trip Point 1 /
2
Subindex 0x01 (900E)
Subindex 0x01 (900F)
5.7 Device Area
(0xF000...0xAFFF)
5.7.1 Semiconductor Device
Profile
Subindex 0x01
Subindex 0x02
5.7.2 Module Profile List
Subindex 0x01
Subindex 0x02
5.7.3 Exceptions
5.7.4 Active Exception Status
Active Exception Status
