tirb45e1 (2019-02) CDGxxxDxx.cp 43
Index
SI
DataType
NV
Access
PM
Name
600E
0x01
BOOL
RO
tx
Status High Trip
0x02
BOOL
RO
tx
Status Low Trip
600F 0x01 BOOL RO tx Status High Trip
0x02
BOOL
RO
tx
Status Low Trip
Status High Trip
0
1
High Trip not assert
High Trip assert
Status Low Trip
0
1
Low Trip not assert
Low Trip assert
Index
SI
DataType
NV
Access
PM
Name
8001
0x12
REAL
x
RW
Offset Customer Specific
Customer-specified Offset which shall be added to the Value parameter of the
Analog Input Sensor instance.
The Offset Customer Specified parameter is a value added from a Zero Adjust
Service to the reported pressure value.
Value shall be calculated as:
Value
*)
= Reported pressure value + AZO
**)
+ OCS
***)
*)
Value (I: 0x6000, SI: 0x11)
**)
Accumulated Zero Offset (I: 0x9000, SI: 0x01)
***)
Offset Customer Specified (I: 0x8001, SI: 0x12)
The High Trip Point is calculated by:
High Trip Point = Value
*)
× Percentage
**)
*)
Value from Piezo Sensor (I: 0x6010, SI: 0x11)
**)
Percentage High Trip Source (I: 0x800E/F, SI: 0x13)
In this case, the High Trip Point value is automatically updated by the device itself.
Any user-written value to the parameter High Trip will be refused with an abort
code.
Usage of High Trip Point is only recommended for measurement range
1000 Torr or 1100 mbar.
The Low Trip Point is a fixed value:
The value defined in Low Trip Point Limit is compared with the pressure value
referenced by the Source Index parameter.
5.4.6 Input Trip Point 2
Subindex 0x01
Subindex 0x02
5.5 Configuration Area
(0x8000…0x8FFF)
5.5.1 Configuration
Capacitance Diaphragm
Subindex 0x12
5.5.2 Configuration Trip Point
