Inficon CDG045D2 User Manual

44 tirb45e1 (2019-02) CDGxxxDxx.cp
Calculating the High Trip Point and Low Trip Point → chapter 5.5.2.
Index
SI
DataType
NV
Access
PM
Name
800E
0x01
BOOL
x
RW
High Trip Enable
0x02
BOOL
x
RW
Low Trip Enable
0x11
REAL
x
RW
High Trip Point Limit
0x12
UDINT
x
RW
High Trip Source Index
0x13 REAL x RW Percentage High Trip
Source
0x14
REAL
x
RW
Low Trip Point Limit
0x15
UDINT
x
RW
Low Trip Source Index
0x16 REAL x RW Percentage Low Trip
Source
0x17
REAL
x
RW
High Trip Hysteresis
0x18
REAL
x
RW
Low Trip Hysteresis
0x1A
UDINT
x
RO
Source Index
High Trip Point
0
1
Disable
Enable
Low Trip Point
0
1
Disable
Enable
High Trip Point Limit: High limit to trigger trip point condition if Input Value
(I 0x900E, SI 0x01) is above this limit.
Object index of High Trip Point Value source. Index of High Trip Point Limit
(I 0x800E, SI 0x11)
Bit 16…31: Index
Bit 08…15: Subindex
Bit 00…07: reserved
It is only possible to reference to "High Trip Point Limit" (I 0x800E, SI 0x11) or
"Input Piezo Module 2" "Sensor Value" (I 0x6010, SI 0x11).
High Trip Point
Time t
in-
active
activein-
active
active
Low Trip Point
Measurement signal
(Pressure p)
Low Trip
Hysteresis
High Trip
Hysteresis
in-
active
5.5.3 Configuration Trip
Point 1
Subindex 0x01
Subindex 0x02
Subindex 0x11
Subindex 0x12
