tirb45e1 (2019-02) CDGxxxDxx.cp 63
(Table "Trip Point Configuration" concluded)
Index Object
Code
Sub
Index
Data
Type
Ac-
cess
B/S PM Name Description
0x800E
0x800F
0x15 UDINT RW B/S Low Trip Source Index
Object index of Low Trip Point Value source.
Bit 16…31: Index
Bit 08…15: Subindex
Bit 00…07: reserved
It is possible to reference to "Low Trip Point Limit"
(I 0x800E1400 / I 0x800F1400) or any other
available input source from another sensor (in case
of combi / multigauges).
0x800E
0x800F
0x16 REAL RW B/S
Percentage Low Trip
Source
Percentage of value referenced by Low Trip Source
Index (I 0x8nnE, SI 0x15) in %.
0x800E
0x800F
0x17 REAL RW B/S High Trip Hysteresis Hysteresis value for High Trip Point.
0x800E
0x800F
0x18 REAL RW B/S Low Trip Hysteresis Hysteresis value for Low Trip Point.
0x800E
0x800F
0x1A UDINT RW B/S Source Index
Object index of active source of Input Value
(I 0x9nnE, SI 0x01).
Bit 16…31: Index
Bit 08…15: Subindex
Bit 00…07: reserved
Trip Point 1
Trip Point 2
CDGxxxD, CDGxxxD2
CDGxxxDhs
→  20
→

44
CDGxxxD, CDGxxxD2
CDGxxxDhs
→  21
→

45
Index Object
Code
Sub
Index
Data
Type
Ac-
cess
B/S PM Name Description
0x9nnx RECORD RO
Information Trip
Point 1 / 2
Trip Point 1 / Trip Point 2
E = Trip Point 1
F = Trip Point 2
0x900E
0x900F
0x01 REAL RO
Input Value of Trip
Point 1 / 2
Trip Point Input value as referenced by Source
Index (I 0x8nnE, SI 0x1A).
Trip Point 1 / 2
CDGxxxD, CDGxxxD2
CDGxxxDhs
→  24
→

49
Information Data of the Modules
