Inficon XTC/3 User Manual

5 - 31
XTC/3 Operating Manual
12
(0x0c)
Input Status Byte (2 Byte) - Each bit represents an input -
(0 = not set, 1 = set)
Input 1 = LSB, Input 9 = 9th bit
0x0100 = Input 1
0x0200 = Input 2
0x0400 = Input 3
0x0800 = Input 4
0x1000 = Input 5
0x2000 = Input 6
0x4000 = Input 7
0x8000 = Input 8
0x0001 = Input 9
0x0300 = Input 1 & 2
0x0101 = Input 1 & 9
0x3800 = Input 4, 5 & 6 etc
13
(0x0d)
Raw Frequency (Int DDS units). - Multiply by 0.0034924596 to
convert to hertz.-
14
(0x0e)
Xtal Fail (Byte) 0 = good crystal / not in Xtal Fail;
1 = failed crystal / in Xtal Fail
15
(0x0f)
Max Power (Byte) 0 = false not in max power;
1 = true in max power
16 (0x10) Crystal Switching (Byte) 0 = not switching; 1 = switching
17 (0x11) End of process (Byte) 0 = False; 1 = True
18 (0x12) Stop (Byte) 0 = False; 1 = True
Table 5-4 Standard Status commands (continued)
S
(0x53)
Command ID
Description Response:
Description (Data Format) Units -Detail-
