Section 8. Auxiliaries. Version 1.01 p3CONCEPT IQ. Installation & Programming Manual.
Auxes
AUXILIARY EVENT TYPE DETAILS
Continued on following page.
No. Auxiliary Event Type: Event On (Valid) when: Event Off (Invalid) when:
0 User (Master) Control/Test only Turned On via NEXT 24 "Auxiliary
Control & Test" Mode.
Turned Off via NEXT 24 "Auxiliary
Control & Test" Mode.
1 Burglary Alarm (Strobe) Any Burglary alarm.
(Alarm on Zone Types 0, 1, 2 or 3)
The Area that the Alarm occured in, is
Disarmed (Turned Off).
2 Fire Alarm Any Fire alarm .
(Alarm on Zone Type 4)
System Dis-armed. (In multi Area
systems, when any Area is disarmed)
3 Area 1 Armed
Area Armed in Normal Mode. Area Disarmed.
4 Area 2 Armed
5 Area 3 Armed
6 Area 4 Armed
7 Area 1 Armed In Home Mode
Area Armed in Home mode. Area Dis-armed in Home mode.
8 Area 2 Armed In Home Mode
9 Area 3 Armed In Home Mode
10 Area 4 Armed In Home Mode
11 Spare
12 Spare
13 Spare
14 Spare
15 Entry (Used for Single Area systems
or Area 1 in Multi Area systems)
General Area / Area 1 Entry timer on. General Area / Area 1 Entry timer off.
16 Exit (Used for Single Area systems
or Area 1 in Multi Area systems)
General Area / Area 1 exit timer on. General Area / Area 1 exit timer off.
17 Zone 1 in Alarm *
Zone in Alarm.
(When Area is Armed)
Off by Auxiliary Timer.
18
Zone 2 in Alarm *
19 Zone 3 in Alarm *
20 Zone 4 in Alarm *
21
Zone 5 in Alarm *
22 Zone 6 in Alarm *
23 Zone 7 in Alarm *
24
Zone 8 in Alarm *
25 Zone 9 in Alarm *
26 Zone 10 in Alarm *
27
Zone 11 in Alarm *
28 Zone 12 in Alarm *
29 Zone 13 in Alarm *
30
Zone 14 in Alarm *
31 Zone 15 in Alarm *
32 Zone 16 in Alarm *
33
Spare
34 Day Alarm* Any “Day alarm” Zone Type Unsealed
when Area not Armed.
Must be programmed to turn Off by an
Auxiliary Timer.
35 Timezone 1
TimeZone Valid. TimeZone Invalid.
36 Timezone 2
37 Timezone 3
38 Timezone 4
