Intel Desktop Board D865PERL Product Guide
12
Table 1. Feature Summary (continued)
Peripheral Interfaces
• Up to eight USB 2.0 ports
 Four ports routed to the back panel
 Four ports routed to two USB headers
• Two Serial ATA channels, via the ICH5R or ICH5, one device per channel
• Two IDE interfaces with ATA-66/100 support
• One diskette drive interface
• One parallel port
• One serial port
• PS/2
*
keyboard and mouse ports
BIOS
• Intel/AMI BIOS
• 4 Mbit symmetrical flash memory
• Support for SMBIOS
• Intel
®
Rapid BIOS Boot
• Intel
®
Express BIOS Update
Power Management
• Support for Advanced Configuration and Power Interface (ACPI)
• Suspend to RAM (STR)
• Wake on USB, PCI, RS-232, PS/2, LAN, and front panel
Hardware Management Hardware monitor with:
• Four fan sensing inputs used to monitor fan activity
• Remote diode temperature sensing
• Intel
®
Precision Cooling Technology fan speed control that automatically
adjusts chassis fan speeds based on system temperature
• Voltage sensing to detect out of range values
Related Links:
For more information about Intel Desktop Board D865PERL, including the Technical Product
Specification (TPS), BIOS updates, and device drivers, go to:
http://support.intel.com/support/motherboards/desktop/

Intel D865PERL Specifications

General

Chipset	Intel 865PE
Socket	Socket 478
Form Factor	ATX
Memory Type	DDR SDRAM
Memory Slots	4
Maximum RAM	4 GB
Expansion Slots	1 x AGP 8x, 5 x PCI
LAN	10/100 Mbps Ethernet
Supported CPU	Intel Pentium 4, Intel Celeron
Storage Interfaces	2 x ATA-100, 2 x SATA
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
Audio	6-channel AC'97
