Installing and Replacing Desktop Board Components
31
Installing and Removing the Desktop Board
WARNING
Only qualified technical personnel should do this procedure. Disconnect the computer from its
power source before performing the procedures described here. Failure to disconnect the power
before you open the computer can result in personal injury or equipment damage.
NOTE
Refer to Appendix B for regulatory requirements.
Refer to your chassis manual for instructions on installing and removing the desktop board.
Figure 4 shows the location of the 11 mounting holes for Desktop Board D865PERL.
OM15475
Figure 4. Location of Desktop Board Mounting Holes
