Intel D865PERL User Manual

Using the BIOS Setup Program
87
Hardware Monitoring Submenu
Main Advanced Security Power Boot Exit
Hardware Monitoring
Note: These measurements are approximate and
should not be used for validation purposes.
Processor Zone Temperature 44
o
C/111
o
F
System Zone 1 Temperature 37
o
C/98
o
F
System Zone 2 Temperature 35
o
C/95
o
F
Processor Fan Speed 2394 RPM
Rear Fan Speed 0 RPM
Rear Fan Speed 0 RPM
Front Fan Speed 0 RPM
m o
Select Screen
n p
Select Item
+1.5Vin 1.480 V Enter
Select ` Sub-Menu
Vccp 1.447 V F1 General Help
+3.3Vin 3.258 V P9 Setup Defaults
+5Vin 5.026 V F10 Save and Exit
12Vin 11.625 V ESC Exit
Table 30. Hardware Monitoring Submenu
Feature Options Description
Processor Zone Temperature No option Displays processor zone temperature.
System Zone 1 Temperature No option Displays system zone 1 temperature.
System Zone 2 Temperature No option Displays system zone 2 temperature.
Processor Fan Speed No option Displays processor fan speed.
Rear Fan Speed No option Displays rear fan speed.
VREG Fan Speed No option Displays VREG fan speed.
Front Fan Speed No option Displays front fan speed.

Intel D865PERL Specifications

General

Chipset	Intel 865PE
Socket	Socket 478
Form Factor	ATX
Memory Type	DDR SDRAM
Memory Slots	4
Maximum RAM	4 GB
Expansion Slots	1 x AGP 8x, 5 x PCI
LAN	10/100 Mbps Ethernet
Supported CPU	Intel Pentium 4, Intel Celeron
Storage Interfaces	2 x ATA-100, 2 x SATA
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
Audio	6-channel AC'97
