Intel D865PERL User Manual

Using the BIOS Setup Program
75
Peripheral Configuration Submenu
Main Advanced Security Power Boot Exit
Peripheral Configuration
Serial Port A [Auto]
Parallel Port [Auto]
Audio [Enabled]
Onboard LAN [Enabled]
m o
Select Screen
n p
Select Item
Enter
Select ` Sub-Menu
F1 General Help
P9 Setup Defaults
F10 Save and Exit
ESC Exit
This submenu shown in Table 21 is used for configuring computer peripherals.
Table 21. Peripheral Configuration Submenu
Feature Options Description
Serial Port A • Disabled
• Enabled
• Auto (default)
Configures serial port A.
Auto assigns the first free COM port, normally COM1,
the address 3F8h, and the interrupt IRQ4.
An * (asterisk) displayed next to an address indicates a
conflict with another device.
Base I/O Address
(This feature is present
only when Serial Port A
is set to Enabled)
• 3F8 (default)
• 2F8
• 3E8
• 2E8
Specifies the base I/O address for serial port A if serial
port A is enabled.
Interrupt
(This feature is present
only when Serial Port A
is set to Enabled)
• IRQ 3
• IRQ 4 (default)
Specifies the interrupt for serial port A if serial port A is
enabled.
Parallel Port • Disabled
• Enabled
• Auto (default)
Configures the parallel port.
Auto assigns LPT1 the address 378h and the
interrupt IRQ7.
An * (asterisk) displayed next to an address indicates a
conflict with another device.
continued

Intel D865PERL Specifications

General

Chipset	Intel 865PE
Socket	Socket 478
Form Factor	ATX
Memory Type	DDR SDRAM
Memory Slots	4
Maximum RAM	4 GB
Expansion Slots	1 x AGP 8x, 5 x PCI
LAN	10/100 Mbps Ethernet
Supported CPU	Intel Pentium 4, Intel Celeron
Storage Interfaces	2 x ATA-100, 2 x SATA
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
Audio	6-channel AC'97
