Intel Desktop Board D865PERL Product Guide
34
Installing and Removing Memory
CAUTION
To be fully compliant with all applicable Intel SDRAM memory specifications, the boards require
DIMMs that support the Serial Presence Detect (SPD) data structure. You can access the PC
Serial Presence Detect Specification at:
http://www.intel.com/technology/memory/pcsdram/spec/
Desktop Board D865PERL has four 184-pin DIMM sockets arranged as DIMM 0 and DIMM 1 in
both Channel A and Channel B, as shown in Figure 9 (color was added to DIMM sockets to show
how to place DIMMs for dual configuration).
Dual Channel Configuration
Before installing DIMMs, read and follow these guidelines for dual channel configuration.
Install a matched pair of DIMMs equal in speed, size, and technology (see Figure 7) in
DIMM 0 in both channels A and B.
Channel A
1 GB, 512 Mb, DDR400
DIMM 0
DIMM 1
Channel B
1 GB, 512 Mb, DDR400
DIMM 0
DIMM 1
Figure 7. Dual Configuration Example 1
If additional memory is to be used, install another matched pair of DIMMs in DIMM 1 in
both channels A and B (see Figure 8).
Channel A
256 MB, 256 Mb, DDR400
DIMM 0
512 MB, 256 Mb, DDR400
DIMM 1
Channel B
256 MB, 256 Mb, DDR400
DIMM 0
512 MB, 256 Mb, DDR400
DIMM 1
Figure 8. Dual Configuration Example 2

Intel D865PERL Specifications

General

Chipset	Intel 865PE
Socket	Socket 478
Form Factor	ATX
Memory Type	DDR SDRAM
Memory Slots	4
Maximum RAM	4 GB
Expansion Slots	1 x AGP 8x, 5 x PCI
LAN	10/100 Mbps Ethernet
Supported CPU	Intel Pentium 4, Intel Celeron
Storage Interfaces	2 x ATA-100, 2 x SATA
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
Audio	6-channel AC'97
