Intel D865PERL User Manual

Intel Desktop Board D865PERL Product Guide
94
Removable Devices Submenu
Main Advanced Security Power Boot Exit
1
st
Drive [1
st
FLOPPY DRIVE]
Specifies the boot
sequence from the
available devices.
Select the boot device
with UpArrow or
DownArrow key. Press
Enter to set the
selections as the
intended boot device.
ARMD = ATAPI Removable
Media Device.
m o
Select Screen
n p
Select Item
Enter
Select ` Sub-Menu
F1 General Help
P9 Setup Defaults
F10 Save and Exit
ESC Exit
The submenu in shown Table 37 is for setting removable devices.
Table 37. Removable Devices Submenu
Feature Options Description
1
st
Removable Device
(Note)
Dependent on installed
removable devices
Specifies the boot sequence from the available
removable devices. To specify boot sequence:
1. Select the boot device with <↑> or <↓>.
2. Press <Enter> to set the selection as the
intended boot device.
Note: This boot device submenu appears only if at least one boot device of this type is installed. This list will
display up to four removable devices, the maximum number of removable devices supported by the BIOS.

Intel D865PERL Specifications

General

Chipset	Intel 865PE
Socket	Socket 478
Form Factor	ATX
Memory Type	DDR SDRAM
Memory Slots	4
Maximum RAM	4 GB
Expansion Slots	1 x AGP 8x, 5 x PCI
LAN	10/100 Mbps Ethernet
Supported CPU	Intel Pentium 4, Intel Celeron
Storage Interfaces	2 x ATA-100, 2 x SATA
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
Audio	6-channel AC'97
