Intel Desktop Board D865PERL Product Guide
56
Connecting Hardware Control and Power Cables
Figure 17 shows the location of the hardware control headers and power connectors.
OM15487
Processor
fan
Chassis
Chassis
rear fan
12 V
Processor core
voltage connector
Main power
connector
1
J5B1
J1F2
J6J2
VREG fan
J1B1
2
1
2
Chassis
intrusion
J6J1
front fan
Figure 17. Location of Hardware Control and Power Connectors
