Intel D865PERL User Manual

Desktop Board Features
15
Table 3. Desktop Board Components
Label Description
A Auxiliary line-in connector (ATAPI-style)
B CD-ROM connector (ATAPI-style)
C Front panel audio header
D AGP connector
E Rear chassis fan header (fan speed control)
F 12 V processor core voltage connector
G VREG fan header
H Processor socket
I Processor fan header
J Intel 82865PE (MCH)
K Channel A DIMM sockets
L Channel B DIMM sockets
M Main power connector
N Diskette drive connector
O Primary IDE connector
P Secondary IDE connector
Q Front chassis fan header (fan speed control)
R Chassis intrusion header
S Serial ATA connectors
T Speaker
U BIOS configuration jumper
V Power LED header
W Front panel header
X Battery
Y Intel 82801ER (ICH5R) or Intel 82801EB (ICH5)
Z USB 2.0 headers
AA 1394a headers (optional)
BB PCI bus add-in card connectors
Related Links:
Go to the following links for more information about
• Intel Desktop Board D865PERL
http://www.intel.com/design/motherbd
http://support.intel.com/support/motherboards/desktop
• supported processors
http://support.intel.com/support/motherboards/desktop
• audio software and utilities
http://www.intel.com/design/motherbd
• LAN software and drivers
http://www.intel.com/design/motherbd

Intel D865PERL Specifications

General

Chipset	Intel 865PE
Socket	Socket 478
Form Factor	ATX
Memory Type	DDR SDRAM
Memory Slots	4
Maximum RAM	4 GB
Expansion Slots	1 x AGP 8x, 5 x PCI
LAN	10/100 Mbps Ethernet
Supported CPU	Intel Pentium 4, Intel Celeron
Storage Interfaces	2 x ATA-100, 2 x SATA
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
Audio	6-channel AC'97
