Intel D865PERL User Manual

Using the BIOS Setup Program
83
USB Configuration Submenu
Main Advanced Security Power Boot Exit
USB Configuration
High-Speed USB [Enabled]
Legacy USB Support [Enabled]
m o
Select Screen
n p
Select Item
Enter
Select ` Sub-Menu
F1 General Help
P9 Setup Defaults
F10 Save and Exit
ESC Exit
The submenu shown in Table 27 is used to configure USB features.
Table 27. USB Configuration Submenu
Feature Options Description
High Speed USB • Disabled
• Enabled (default)
Disable this option when a USB 2.0 driver is not
available.
Legacy USB Support • Disabled
• Enabled (default)
Enables support for legacy USB.

Intel D865PERL Specifications

General

Chipset	Intel 865PE
Socket	Socket 478
Form Factor	ATX
Memory Type	DDR SDRAM
Memory Slots	4
Maximum RAM	4 GB
Expansion Slots	1 x AGP 8x, 5 x PCI
LAN	10/100 Mbps Ethernet
Supported CPU	Intel Pentium 4, Intel Celeron
Storage Interfaces	2 x ATA-100, 2 x SATA
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
Audio	6-channel AC'97
